Product information
| Specification | Details |
|---|---|
| Channel Number | 48 |
| Oscillator Type | PLL synthesizer |
| Carrier Frequencies | 556.710-575.980MHz |
| Reference Deviation | +/-5KHZ (-60dBV, 1KHz input) |
| Signal to Noise Ratio | 82dB or more |
| RF Output Power | 10mW |
| Distortion | 0.1% or less |
| Antenna | 1/4λ wire antenna |
| Headphone Output Level | 30mW (16 ohm) |
| Receive Sensitivity | -98dBm |
| Frequency Response | 40Hz to 18KHz (+/-3dB) |
| Reference Audio Input Level | -60dBV (MIC input, 0dB attenuation) |
| Power Requirement | Built-in Li-ion battery 1600mAh / DC5v (USB TYPE-C) / Continuous time: 10 hours, Charging time: 2.5 hours (5V/1A) |
| Dimensions | 60x24x90mm (2.4″x 0.9″x 3.5″) |
| Weight | 149g (5.3oz) |
- Channel Number: 48
- RF Output Power: 10mW
- Battery: Built-in Li-ion, 1600mAh
- Range: Up to 70m (230ft)
- Weight: 149g (5.3oz)
